Self-propelled lawn mower with three cutting methods
When you buy locally from Atlantic Outdoor your machine will be uncrated, assembled and inspected by our certified technicians. All tractors and zeroturns come with a full tank of gas. Delivery is available to all Maritime provinces and we ship Canada-wide. We will register the warranty for you. Customers are never charged incoming freight charges or tire levis on in stock units.
Questions about our units? Call us at 506-387-3000 or email us at sales@atlanticoutdoor.ca
FEATURES
3-in-1 cutting system
The lawn mower offers flexible adaptation to different needs and areas thanks to several cutting options. Collection for a tidy lawn, BioClip® (mulching) for lawn fertilisation, and side discharge for less frequently cut areas.
Ergonomic handle
Ergonomic angle of the handle in combination with easy to reach bail arms makes operation easy.
Easy adjustable handle
Quick and easy adjustment of the handle in two different heights.
Easy grip for lifting in the front
Easy-to-grip lifting handle facilitates lifting into storage spaces, the car or carrying up stairs
Central cutting height adjustment
Quick and easy adjustment of the grass cutting height. One lever controls the whole deck.
Easy foldble handle bar
Easily fold the handle to minimize space required for storing and transportation.
SPECIFICATIONS
| Engine |
(CA)
SKU: 970 48 84‑03
|
|---|---|
Engine Power (As rated by the engine manufacturer)1 |
3.6 hp |
Engine brand |
Husqvarna |
Engine name |
HS 166A |
Cylinder displacement |
10.1 cu.inch |
Engine lubrication type |
Splash |
Engine cooling |
Air |
| Emission |
(CA)
SKU: 970 48 84‑03
|
|---|---|
Exhaust emissions (CO₂ EU V)2 |
922.38 g/kWh |
| Material |
(CA)
SKU: 970 48 84‑03
|
|---|---|
Cutting deck material |
Steel |
Rims, material |
Plastic |
| Cutting deck |
(CA)
SKU: 970 48 84‑03
|
|---|---|
Cutting methods |
Collection/BioClip®/Side discharge |
Cutting width |
20 in |
BioClip® kit |
Available as accessory |
BioClip® plug |
Included |
Cutting height steps |
7 |
Cutting height adjustment |
Central |
Cutting Height Max |
2.95 in |
Cutting height min |
0.98 in |
| Drive system |
(CA)
SKU: 970 48 84‑03
|
|---|---|
Drive system |
Self-propelled |
Drive wheels |
Rear |
Speed forward max |
2.2 mph |
Speed forward min |
0 mph |
| Equipment |
(CA)
SKU: 970 48 84‑03
|
|---|---|
Collector type |
Fabric with dust blocker |
Collection Volume |
2.3 cu.feet |
Handle type |
Ergonomic Handle (Bag Through) |
Handle height adjustment |
2 Step |
Wheel bearing, front/rear |
Yes/Yes |
Foldable handle |
Yes |
Soft grip |
Yes |
Side adjustable handle |
No |
Throttle control |
No |
Water hose connection |
No |
Blade brake clutch (BBC) |
No |
| Dimensions |
(CA)
SKU: 970 48 84‑03
|
|---|---|
Wheel size, Front |
8 in |
Wheel size, Rear |
8 in |
Weight |
69.7 lbs |
Wheelbase |
26 in |
| Sound and noise |
(CA)
SKU: 970 48 84‑03
|
|---|---|
Sound pressure level at operators ear (LpA) |
86 dB(A) |
Sound power level, measured |
96 dB(A) |
Sound power level, guaranteed (LWA) |
98 dB(A) |
| Vibration |
(CA)
SKU: 970 48 84‑03
|
|---|---|
Vibrations handlebar |
8.5 m/s² |
DISCLAIMER
Please note product images, specs and other information provided may change at any time without notice and may not reflect the units in stock at dealer location. We pride ourselves on working with companies who are constantly researching and developing better products and as such specs may change with little or no notice.
